Persistent SSH Tunneling

Imaging the sitaution that we need to access services behind NAT/firewall, how to achieve it?

The answer is reverse SSH tunneling.

Reverse SSH is a technique through which you can access systems that are behind a firewall from the outside world. In that case, the server behind NAT/firewall does an SSH and through the port forwarding makes sure that you can SSH back to the server machine.

In above diagram, internal server will establish a SSH connection to jumpbox then opens a listenning port on jumpbox, all traffics to this listenning port will be forwarded to a specified port at internal server side.

By using reverse SSH tunneling, we can publish an internal listenning port to internet, here are the steps to achieve it.

0 Prerequisite

All we need is a VM which has a public IP address to serve as the jumpbox, SSH service need to be installed. In Azure, we can simply deploy a Ubuntu 16.04 VM.

1 Configure AutoSSH at Internal Server Side

From the internal server we want to publish service, install AutoSSH, refer to AutoSSH

autossh is a program to start a copy of ssh and monitor it, restarting it as necessary should it die or stop passing traffic.

Presume it's Ubuntu 16.04 server, the commands used to install AutoSSH will be

sudo -i
apt update
apt install autossh

Once AutoSSH is installed, create a service configuration to configure AutoSSH as a service.

vi /lib/systemd/system/autossh.service

Copy/Paste below content into autossh.service then save.

[Unit]
Description=autossh
Wants=network-online.target
After=network-online.target

[Service]
Type=simple
User=<YOUR_USER_NAME>
EnvironmentFile=/etc/default/autossh
ExecStart=
ExecStart=/usr/bin/autossh $SSH_OPTIONS
Restart=always
RestartSec=60

[Install]
WantedBy=multi-user.target

Now, we also need to create a configuration at /etc/default/autossh.

vi /etc/default/autossh

Copy/Paste below content into the file then save

AUTOSSH_POLL=60
AUTOSSH_FIRST_POLL=30
AUTOSSH_GATETIME=0
AUTOSSH_PORT=22000
SSH_OPTIONS="-N -R JUMPBOX_LISTEN_PORT:localhost:INTERNAL_SERVER_PORT JUMPBOX_FQDN -i /home/YOUR_USER_NAME/.ssh/id_rsa"

JUMPBOX_LISTEN_PORT: A listening port will be created at jumpbox
INTERNAL_SERVER_PORT: Internal server service's port
JUMPBOX_FQDN: Jumpbox's FQDN or IP address

Before enable & start AutoSSH service, make sure YOUR_USER_NAME has

• private key to connect to jumpbox, private key should be stored at ~/.ssh/id_rsa.
• Have jumpbox server key fingerprint stored and able to SSH into the jumpbox, simply run "ssh JUMPBOX_FQDN" and type Yes to store the key fingerprint at ~/.ssh/known_hosts

Enable and start AutoSSH

systemctl daemon-reload
systemctl enable autossh
systemctl start autossh

2 Configure JumpBox

By default, reverse SSH tunneling only creates a listening port at loopback interface, that means the listening port is on 127.0.0.1. If you run netstat -lptn, you would see

Active Internet connections (only servers)
Proto Recv-Q Send-Q Local Address           Foreign Address         State       PID/Program name
tcp        0      0 127.0.0.1:<PORT>       0.0.0.0:*               LISTEN      106872/sshd: <YOUR_USER_NAME>

We can use iptable to forward physical interface's network to loopback interface, to do that

• Allow the port proxy to route using loopback addresses

sudo -i
echo "net.ipv4.conf.all.route_localnet=1" >> /etc/sysctl.conf
sysctl -p /etc/sysctl.conf

• Configure iptables

iptables -t nat -I PREROUTING -p tcp --dport JUMPBOX_LISTEN_PORT -j DNAT --to-destination 127.0.0.1:JUMPBOX_LISTEN_PORT
# Save iptables rules persistently
apt install iptables-persistent
iptables-save > /etc/iptables/rules.v4

3 Configure Azure NSG to Allow Inbound Traffics to JUMPBOX_LISTEN_PORT

From Azure portal, choose JumpBox VM, Networking->Add inbound port, add inbound security rule to allow traffics to JUMPBOX_LISTEN_PORT.

4 Connect to Internal Server

Now you are able to access internal server service port through JumpBox server, for example, if the published port is SSH, you can acccess it with command below

ssh YOUR_USER_NAME@JUMPBOX_FQDN:JUMPBOX_LISTEN_PORT
